Tesla™
Power Anytime, Anywhere
Power Anytime, Anywhere
TI4676 MPU-24
NSN: 6140014675710
- Currently being flown in the UH-1, S-61, Falcon 200, AH-1, and the Dauphin.
- Ideal for testing and troubleshooting avionics, and weapons systems.
- Faster, more reliable starts.
- Built in Capacity Meter/Recharge State Indicator.
- Non-hazardous, dry-cell technology with no risk of thermal runaway.
- 5 to 7 year battery service life.
- Plugs into ac power to recharge cells.
- Back-charges off of dc aircraft bus.
TI4676 MPU-24 Specifications
| DC Output: | 1500 peak starting amps 10 amps continuous @ 28.5 Vdc (when plugged into ac power) 33 amp hours (797 watt hours) with ac power 23 amp hours (512 watt hours) of rechargeable battery power without ac |
| AC Input: | Operates and charges from Single Phase 100-260 Vac 45-450 Hz 5.5 amps @ single phase 120 Vac 2.75 amps @ single phase 240 Vac |
| Recharging Rate: | 143 minutes (from full discharge) @ 25°C |
| Dimensions: | 10.85" L x 9.68" W x 9.43" H 275.6 mm x 245.87 mm x 239.52 mm |
| Weight: | 53 lbs (24 kg) |
| Warranty: | 3 Years |
Alternate NSN Code: TI4676 MPU-24 / NSN: 6140-01-467-5710
